Name: Moxa 2-Port Advanced Serial-to-Ethernet Modbus Gateways MGATE MB3170I
SKU: 553670

Product Details ＋

Whether wired or wireless, single or multiple serial ports, Moxa’s Modbus TCP gateway solutions connect Modbus RTU, DNP3, J1939, and PROFIBUS devices to Modbus TCP networks, making configuration, troubleshooting, and conversion quick and easy.

Specifications:

Converter Type: Media

Family Name: MGate

Isolation Voltage: 2 kV

Mounting Type: DIN Rail Mount

Number of IO Ports: 1

Operating Temperature: 0 to 60 C

Protocol Type: Modbus TCP

Series: MGate MB3170 Series

Features and Benefits:

• Supports Auto Device Routing for easy configuration

• Supports route by TCP port or IP address for flexible deployment

• Connects up to 32 Modbus TCP servers

• Connects up to 31 or 62 Modbus RTU/ASCII slaves

• Accessed by up to 32 Modbus TCP clients (retains 32 Modbus requests for

each Master)

• Supports Modbus serial master to Modbus serial slave communications

• Built-in Ethernet cascading for easy wiring

• 10/100BaseTX (RJ45) or 100BaseFX (single mode or multi-mode with SC/ST

connector)

• Emergency request tunnels ensure QoS control

• Embedded Modbus traffic monitoring for easy troubleshooting

• Serial port with 2 kV isolation protection (for “-I” models)

• -40 to 75°C wide operating temperature models available

• Supports redundant dual DC power inputs and 1 relay output

Moxa 2-Port Advanced Serial-to-Ethernet Modbus Gateways MGATE MB3170I
